FUNCTION
Aluminium door handles with Alumil Patented design and logo
TECHNICAL FEATURES
•
5 versions available
- Paired handle with cylinder rosette (oval)
- Paired handle with interior door rosette (round)
- Paired or single handle with full body rosette
- Paired handle with full body rosette and fixed outside knob
- Single cranked handle
•
Handles without full body rosette come with separate spring and have Quick-
Fit® pin system
•
Handles with full body rosette have pins attached on body
•
Cranked handle allows easy operation with increased handling space for
outside opening doors
•
For in-out handle installation approximate sash width should not be more
than 75mm
•
Cranked handle comes without pin, therefore any 8mm spindle can be
installed in any length
MATERIALS
•
Full aluminium main body
•
Polyamide base
•
Aluminium base cover
•
Galvanized pin
SURFACE COATING
•
White powder coating RAL 9016
•
Black powder coating RAL 9712 mat
•
Brown powder coating RAL 8707
•
Silver / Titanium / Bronze anodized
•
Mill finish / Special colors upon request
CERTIFICATION
•
Durability:
Handle set with full plate:
- 100.000 cycles - Grade 6 [EN 1906:2012]
- 182.500 cycles - Independent test for residential use
Handle set with separate rosette:
- 200.000 cycles - Grade 7 [EN 1906:2012]
- 255.500 cycles - Test for non-residential use
•
Corrosion resistance: >240 hours, Grade 4 [EN 1906:2012]
•
10 Year operational Guarantee
•
ISO 9001 / ISO 14001
•
Alumil 5 Year Guarantee
EX-3809788033 DOOR HANDLE SET WITH PLATE ALUMIL 85mm LIGHT SILVER F1
EX-3809788006 DOOR HANDLE SET WITH PLATE ALUMIL 85mm BROWN
EX-3809788002 DOOR HANDLE SET WITH PLATE ALUMIL 85mm WHITE
EX-3809788061 DOOR HANDLE SET WITH PLATE ALUMIL 85mm BLACK MATT
EX-3809788007 DOOR HANDLE SET WITH PLATE ALUMIL 85MM BRONZE
EX-3809788067 DOOR HANDLE SET WITH PLATE ALUMIL 85mm TITANIUM F9
EX-3809761033 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL LIGHT SILVER F1
EX-3809761006 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL BROWN
EX-3809761002 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL WHITE
EX-3809761061 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL BLACK MATT
EX-3809761007 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL F4 BRONZE
EX-3809761067 DOOR HANDLE SET WITH NARROW ROSETTE ALUMIL TITANIUM F9
EX-3809788133 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85mm LIGHT SILVER F1
EX-3809788106 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85MM BROWN
EX-3809788102 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85mm WHITE
EX-3809788161 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85mm BLACK MATT
EX-3809788107 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85mm BRONZE
EX-3809788167 SINGLE DOOR HANDLE WITH PLATE ALUMIL 85mm TITANIUM F9
EX-3809868133 HANDLE SET INTERIOR DOOR ALUMIL LIGHT SILVER F1
EX-3809788233 DOOR HANDLE SET FIXED OUTSIDE ALUMIL LIGHT SILVER F1
EX-3809771033 CRANKED DOOR HANDLE SINGLE LIGHT SILVER F1
EX-3801810500 SPINDLE FOR CRANKED HANDLE 8x105mm
EX-3801812500 SPINDLE FOR CRANKED HANDLE 8x125mm
EX-3801813500 SPINDLE FOR CRANKED HANDLE 8x135mm
EX-3801814500 SPINDLE FOR CRANKED HANDLE 8x145mm
EX-3801815500 SPINDLE FOR CRANKED HANDLE 8x155mm
EX-3801808500 SPINDLE FOR CRANKED HANDLE 8x85mm
EX-3804682700 SPINDLE FOR CRANKED HANDLE 8x170mm
EX-3804683500 SPINDLE FOR CRANKED HANDLE 8x190mm
EX-3801853100 SINGLE HANDLE SPINDLE 8x65mm
EX-3801855500 SINGLE HANDLE SPINDLE 8x75mm
EX-3807196700 SINGLE HANDLE SPINDLE 8x85mm
EX-3802232133 CYLINDER ESCUTCHEON 29x68mm LIGHT SILVER F1
EX-3802232106 CYLINDER ESCUTCHEON 29x68mm BROWN
EX-3802232102 CYLINDER ESCUTCHEON 29x68mm WHITE
EX-3802232107 CYLINDER ESCUTCHEON 29x68mm BRONZE
EX-3802232167 CYLINDER ESCUTCHEON 29x68mm TITANIUM
EX-3802232161 CYLINDER ESCUTCHEON 29x68mm BLACK MATT
EX-3809771133 ESCUTCHEON FOR CRANKED HANDLE LIGHT SILVER F1
ALUMIL 8mm PIN DOOR HANDLES
CODES & DESCRIPTIONS
