FUNCTION
Multi use building material for interior and exterior use
TECHNICAL FEATURES
•
Available in multi-wall and solid sheets
•
Available in custom dimensions to minimize excess
•
4, 6, 8, 10, 16, 20, 25, 32, 40mm for multi-wall
•
2, 3, 4, 5, 6, 8, 10mm for solid sheets
•
Lightweight, no-brake, heat insulating, sound insulating, UV
protected
•
Perfect for atriums, sound barriers, kiosks, space separation
•
Dust repelling, easy to clean
•
Fully tested and calculated for solar heat gains
•
Light transmission, shading coefficient, thermal expansion
•
2 types available (Polybat, Polycarb)
MATERIALS
•
Polycarbonate
•
UV resistant top side (indicated)
•
Double UV resistant side upon request
SURFACE COATING
•
Color is part of the raw material
•
Colors for multiwall: clear, white, green, blue, bronze
•
Colors for solid: opal, clear, bronze
•
Easy peel protective film on all surfaces
CERTIFICATION
•
Leed USGBC LEED-NC v2.2 credits
•
Class A fire reaction ASTM E-84
•
Alumil 10 Year Guarantee on Polycarb
•
Alumil 5 Year Guarantee on Polybat
ALUMIL POLYCARBONATE SHEETS
CODES & DESCRIPTIONS
EX-7710262030 SOLID POLYCARBONATE SHEET 2X2050X6100 CLEAR EX-7740420000 EUROCARB 4X6000X2100mm 2 WALL CLEAR
EX-7741036000 EUROCARB 10X6000X2100mm 3 WALL REFLECTIVE
EX-7710262031 SOLID POLYCARBONATE SHEET 2X2050X6100 OPAL
EX-7740421000 EUROCARB 4X6000X2100mm 2 WALL WHITE
EX-7741037000 EUROCARB 10X6000Χ2100mm 3 WALL GREY
EX-7710262032 SOLID POLYCARBONATE SHEET 2X2050X6100 BRONZE EX-7740422000 EUROCARB 4X6000X2100mm 2 WALL BRONZE EX-7741651000 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL CLEAR
EX-7710362130 SOLID POLYCARBONATE SHEET 3Χ2050Χ6100 CLEAR EX-7740423000 EUROCARB 4X6000X2100mm 2 WALL BLUE
EX-7741651100 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL OPAL
EX-7710362131 SOLID POLYCARBONATE SHEET 3Χ2050Χ6100 OPAL
EX-7740424000 EUROCARB 4X6000X2100mm 2 WALL GREEN EX-7741651200 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL BRONZE
EX-7710362132 SOLID POLYCARBONATE SHEET 3Χ2050Χ6100 BRONZE EX-7740620000 EUROCARB 6X6000X2100mm 2 WALL CLEAR
EX-7741651300 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL BLUE
EX-7710462230 SOLID POLYCARBONATE SHEET 4Χ2050Χ6100 CLEAR EX-7740621000 EUROCARB 6X6000X2100mm 2 WALL WHITE
EX-7741651400 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL GREEN
EX-7710462231 SOLID POLYCARBONATE SHEET 4Χ2050Χ6100 OPAL
EX-7740622000 EUROCARB 6X6000X2100mm 2 WALL BRONZE EX-7741651500 EUROCARB SHEET RDC 16x6000x2100mm 5 WALL REFLECTING
EX-7710462232 SOLID POLYCARBONATE SHEET 4X2050X6100 BRONZE EX-7740623000 EUROCARB 6X6000X2100mm 2 WALL BLUE
EX-7742051000 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL CRYSTAL
EX-7710562030 SOLID POLYCARBONATE SHEET 5Χ2050Χ6100 CLEAR EX-7740624000 EUROCARB 6X6000X2100mm 2 WALL GREEN EX-7742051100 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL OPAL
EX-7710562031 SOLID POLYCARBONATE SHEET 5Χ2050Χ6100 OPAL
EX-7740830000 EUROCARB 8X6000Χ2100mm 3 WALL CLEAR
EX-7742051200 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL BRONZE
EX-7710562032 SOLID POLYCARBONATE SHEET 5X2050X6100 BRONZE EX-7740831000 EUROCARB 8X6000Χ2100mm 3 WALL WHITE
EX-7742051300 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL BLUE
EX-7710662030 SOLID POLYCARBONATE SHEET 6Χ2050Χ6100 CLEAR EX-7740832000 EUROCARB 8X6000Χ2100mm 3 WALL BRONZE EX-7742051400 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL GREEN
EX-7710662031 SOLID POLYCARBONATE SHEET 6Χ2050Χ6100 OPAL
EX-7740833000 EUROCARB 8X6000Χ2100mm 3 WALL BLUE
EX-7742051500 EUROCARB SHEET RDC 20X6000X2100mm 5 WALL REFLECTING
EX-7710662032 SOLID POLYCARBONATE SHEET 6X2050X6100 BRONZE EX-7740834000 EUROCARB 8X6000Χ2100mm 3 WALL GREEN EX-7742551000 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL CRYSTAL
EX-7710862030 SOLID POLYCARBONATE SHEET 8X2050X6100 CLEAR EX-7741030000 EUROCARB 10X6000Χ2100mm 3 WALL CLEAR EX-7742551100 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL OPAL
EX-7710862031 SOLID POLYCARBONATE SHEET 8X2050X6100 OPAL
EX-7741031000 EUROCARB 10X6000Χ2100mm 3 WALL WHITE EX-7742551200 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL BRONZE
EX-7710862032 SOLID POLYCARBONATE SHEET 8X2050X6100 BRONZE EX-7741032000 EUROCARB 10X6000Χ2100mm 3 WALL BRONZE EX-7742551300 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL BLUE
EX-7711062030 SOLID POLYCARBONATE SHEET 10X2050X6100 CLEAR EX-7741033000 EUROCARB 10X6000Χ2100mm 3 WALL BLUE
EX-7742551400 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL GREEN
EX-7711062031 SOLID POLYCARBONATE SHEET 10X2050X6100 OPAL
EX-7741034000 EUROCARB 10X6000Χ2100mm 3 WALL GREEN EX-7742551500 EUROCARB SHEET RDC 25X6000X2100mm 5 WALL REFLECTING
EX-7711062032 SOLID POLYCARBONATE SHEET 10X2050X6100 BRONZE EX-7746208800 POLYBAT 6X6000Χ2100mm 2 WALL CLEAR
EX-7740308800 POLYBAT 10X6000Χ2100mm 3 WALL CLEAR
EX-7746218800 POLYBAT 6X6000Χ2100mm 2 WALL WHITE
EX-7740318800 POLYBAT 10X6000Χ2100mm 3 WALL WHITE
EX-7746228800 POLYBAT 6X6000Χ2100mm 2 WALL BRONZE
EX-7740328800 POLYBAT 10X6000Χ2100mm 3 WALL BRONZE
