FUNCTION
Aluminium and plastic rollers for all Alumil sliding systems
TECHNICAL FEATURES
•
Perfect fit for Alumil sliding systems
•
Single and double wheel rollers
•
Quick and easy installation
•
Installation with screw or fixing plate
•
Designed to achieve maximum adjustment
•
One-man adjustment with sash on frame
•
Special composite wheel cover for smooth and silent
operation
•
In cases brush installed for guide rail cleaning
•
Side to side self adjusting wheel
MATERIALS
•
Extruded aluminium or polyamide main body
•
Galvanized pins and screws
•
Special polymer wheels
SURFACE COATING
•
Not treated (standard aluminum or black polyamide)
CERTIFICATION
•
Durability:
- Grade 3 - 10.000 test cycles [EN 13126.15]
- EX-6002565000 at 130kg
- Grade 4 - 15.000 test cycles [EN 13126.15]
- INT-6000044000 at 90kg
- Grade 5 - 25.000 test cycles [EN 13126.15]
- EX-6000214000 at 100kg
- EX-6000230400 at 45kg
- EX-6000210100 at 45kg
- EX-6000235000 at 100kg
- EX-6001200000 at 100kg
- EX-6001460000 at 100kg
- EX-6000120100 at 22kg
- EX-6000255000 at 70kg
- Ongoing tests for other articles
•
Alumil 5 Year Guarantee
EX-6000120100 ROLLER ALUMINIUM SINGLE WITH PLATE M9000 & M9200
EX-6000210100 ROLLER PLASTIC DOUBLE M9000, M9200, M900, M9050
EX-6000230400 ROLLER ALUMINIUM DOUBLE WITH PLATE M9000 & M9200
EX-6000220600 ROLLER PLASTIC SINGLE M9028
EX-6000255000 ROLLER ALUMINIUM DOUBLE S450
EX-6000110100 ROLLER PLASTIC SINGLE M900
EX-6000114000 ROLLER ALUMINIUM SINGLE WITH PLATE M12000 & M14000
EX-6002900800 ROLLER PLASTIC SINGLE M9008
EX-6000214000 ROLLER ALUMINIUM DOUBLE WITH PLATE M12000 & M14000 EX-6000235000 ROLLER PLASTIC DOUBLE S350
EX-6001200000 ROLLER ALUMINIUM DOUBLE M12500
INT-6000044000 ROLLER PLASTIC DOUBLE S440
EX-6000185000 ROLLER ALUMINIUM SINGLE M868
EX-6001460000 ROLLER ALUMINIUM DOUBLE M14600
EX-6002565000 SET 4 PCS ROLLERS ALUMINIUM DOUBLE S650
EX-6000207000 ROLLER ALUMINIUM DOUBLE WITH PLATE M9242
INT-6000273700 ROLLER ALUMINIUM DOUBLE S70737
ALUMIL ROLLERS
CODES & DESCRIPTIONS
