FUNCTION
Screws for certified fabrication of Alumil systems
TECHNICAL FEATURES
•
Philips (Standard Cross) Head on all screws
•
All Alumil systems are certified with Alumil screws
•
A2 stainless screws do not contaminate the aluminium
and are highly resistant to corrosions
•
Galvanized screws are stronger and more elastic
•
Self drilling screws allow for faster application but only
single layered fixing is possible
•
Tapping screws require pre-drilling
MATERIALS
•
A2 Stainless steel (AISI 304)
•
Standard steel cold dipped galvanized
SURFACE COATING
•
No additional surface coating
CERTIFICATION
•
DIN / ISO Certified
•
Alumil 5 Year Guarantee
EX-7622913000
CSK A2 2,9x13 PH
EX-7622919000
CSK A2 2,9x19 PH
EX-7981223913
CSK Α2 3,9X13 PH
EX-7981223919
CSK Α2 3,9X19 PH
EX-7981223925
CSK Α2 3,9X25 PH
EX-7981224295
CSK Α2 4,2X9,5 PH
EX-7981224213
CSK Α2 4,2X13 PH
EX-7981224219
CSK Α2 4,2X19 PH
EX-7981224225
CSK Α2 4,2X25 PH
EX-7981224232
CSK Α2 4,2X32 PH
EX-7981224238
CSK Α2 4,2X38 PH
EX-7981224250
CSK Α2 4,2X50 PH
EX-7981224813
CSK Α2 4,8X13 PH
EX-7981224819
CSK Α2 4,8X19 PH
EX-7981224825
CSK Α2 4,8X25 PH
EX-7981224832
CSK Α2 4,8X32 PH
EX-7981224838
CSK Α2 4,8X38 PH
EX-7981224850
CSK Α2 4,8X50 PH
EX-7981224860
CSK Α2 4,8X60 PH
EX-7981224870
CSK Α2 4,8X70 PH
EX-7981225519
CSK Α2 5,5X19 PH
EX-7981225525
CSK Α2 5,5X25 PH
EX-7981225532
CSK Α2 5,5X32 PH
EX-7981225538
CSK Α2 5,5X38 PH
EX-7981225550
CSK Α2 5,5X50 PH
EX-7981225560
CSK Α2 5,5X60 PH
EX-7981225570
CSK Α2 5,5X70 PH
EX-7981225580
CSK Α2 5,5X80 PH
EX-7982123913 PAN Α2 3,9X13 PH
EX-7982123919 PAN Α2 3,9X19 PH
EX-7982123925 PAN Α2 3,9X25 PH
EX-7982124295 PAN Α2 4,2X9,5 PH
EX-7982124213 PAN Α2 4,2X13 PH
EX-7982124219 PAN Α2 4,2X19 PH
EX-7982124225 PAN Α2 4,2X25 PH
EX-7982124232 PAN Α2 4,2X32 PH
EX-7982124238 PAN Α2 4,2X38 PH
EX-7982124250 PAN Α2 4,2X50 PH
EX-7982124813 PAN Α2 4,8X13 PH
EX-7982124819 PAN Α2 4,8X19 PH
EX-7982124825 PAN Α2 4,8X25 PH
EX-7982124832 PAN Α2 4,8X32 PH
EX-7982124838 PAN Α2 4,8X38 PH
EX-7982124850 PAN Α2 4,8X50 PH
EX-7982124860 PAN Α2 4,8X60 PH
EX-7982124870 PAN Α2 4,8X70 PH
EX-7982125519 PAN Α2 5,5X19 PH
EX-7982125525 PAN Α2 5,5X25 PH
EX-7982125532 PAN Α2 5,5X32 PH
EX-7982125538 PAN Α2 5,5X38 PH
EX-7982125550 PAN Α2 5,5X50 PH
EX-7982125560 PAN Α2 5,5X60 PH
EX-7982125570 PAN Α2 5,5X70 PH
EX-7982125580 PAN Α2 5,5X80 PH
EX-7983223913 CSK GALV 3,9X13 PH
EX-7983223919 CSK GALV 3,9X19 PH
EX-7983223925 CSK GALV 3,9X25 PH
EX-7983224295 CSK GALV 4,2X9,5 PH
EX-7983224213 CSK GALV 4,2X13 PH
EX-7983224219 CSK GALV 4,2X19 PH
EX-7983224225 CSK GALV 4,2X25 PH
EX-7983224232 CSK GALV 4,2X32 PH
EX-7983224238 CSK GALV 4,2X38 PH
EX-7983224250 CSK GALV 4,2X50 PH
EX-7983224813 CSK GALV 4,8X13 PH
EX-7983224819 CSK GALV 4,8X19 PH
EX-7983224825 CSK GALV 4,8X25 PH
EX-7983224832 CSK GALV 4,8X32 PH
EX-7983224838 CSK GALV 4,8X38 PH
EX-7983224850 CSK GALV 4,8X50 PH
EX-7983224860 CSK GALV 4,8X60 PH
EX-7983225519 CSK GALV 5,5X19 PH
EX-7983225525 CSK GALV 5,5X25 PH
EX-7983225532 CSK GALV 5,5X32 PH
EX-7983225538 CSK GALV 5,5X38 PH
EX-7983225550 CSK GALV 5,5X50 PH
EX-7983225575 CSK GALV 5,5X75 PH
EX-7983226319 CSK GALV 6,3X19 PH
EX-7983226332 CSK GALV 6,3X32 PH
EX-7983226350 CSK GALV 6,3X50 PH
EX-7983226375 CSK GALV 6,3X75 PH
EX-7984123913 PAN GALV 3,9X13 PH
EX-7984123919 PAN GALV 3,9X19 PH
EX-7984123925 PAN GALV 3,9X25 PH
EX-7984124295 PAN GALV 4,2X9,5 PH
EX-7984124213 PAN GALV 4,2X13 PH
EX-7984124219 PAN GALV 4,2X19 PH
EX-7984124225 PAN GALV 4,2X25 PH
EX-7984124232 PAN GALV 4,2X32 PH
EX-7984124238 PAN GALV 4,2X38 PH
EX-7984124250 PAN GALV 4,2X50 PH
EX-7984124813 PAN GALV 4,8X13 PH
EX-7984124819 PAN GALV 4,8X19 PH
EX-7984124825 PAN GALV 4,8X25 PH
EX-7984124832 PAN GALV 4,8X32 PH
EX-7984124838 PAN GALV 4,8X38 PH
EX-7984124850 PAN GALV 4,8X50 PH
EX-7984124860 PAN GALV 4,8X60 PH
EX-7984125519 PAN GALV 5,5X19 PH
EX-7984125525 PAN GALV 5,5X25 PH
EX-7984125532 PAN GALV 5,5X32 PH
EX-7984125538 PAN GALV 5,5X38 PH
EX-7984125550 PAN GALV 5,5X50 PH
EX-7984125575 PAN GALV 5,5X75 PH
EX-7984126319 PAN GALV 6,3X19 PH
EX-7984126332 PAN GALV 6,3X32 PH
EX-7984126350 PAN GALV 6,3X50 PH
EX-7984126375 PAN GALV 6,3X75 PH
EX-7985223919 CSK DR GALV 3,9X19 PH
EX-7985223925 CSK DR GALV 3,9X25 PH
EX-7985224219 CSK DR GALV 4,2X19 PH
EX-7985224225 CSK DR GALV 4,2X25 PH
EX-7985224232 CSK DR GALV 4,2X32 PH
EX-7985224819 CSK DR GALV 4,8X19 PH
EX-7985224825 CSK DR GALV 4,8X25 PH
EX-7985224832 CSK DR GALV 4,8X32 PH
EX-7985225525 CSK DR GALV 5,5X25 PH
EX-7986124219 PAN DR GALV 4,2X19 PH
EX-7986224225 PAN DR GALV 4,2X25 PH
EX-7986224232 PAN DR GALV 4,2X32 PH
EX-7986124819 PAN DR GALV 4,8X19 PH
EX-7986224825 PAN DR GALV 4,8X25 PH
EX-7986224832 PAN DR GALV 4,8X32 PH
EX-7986225525 PAN DR GALV 5,5X25 PH
EX-7629651901 ALLEN 5,5X19 A2
EX-7629652501 ALLEN 5,5X25 A2
EX-7629653001 ALLEN 5,5X30 A2
EX-7629653501 ALLEN 5,5X35 A2
EX-7629653801 ALLEN 5,5X38 A2
EX-7629654001 ALLEN 5,5X40 A2
EX-7629654501 ALLEN 5,5X45 A2
EX-7629655001 ALLEN 5,5X50 A2
EX-7629655501 ALLEN 5,5X55 A2
EX-7629655601 ALLEN 5,5X60 A2
EX-7629656501 ALLEN 5,5X65 A2
EX-7629655701 ALLEN 5,5X70 A2
STAINLESS STEEL A2 SCREWS
GALVANIZED SCREWS
________________________________________________
ALUMIL SYSTEM SCREWS
CODES & DESCRIPTIONS
Drilling Screw
CSK Head
Pan Head
Allen Screw
