FUNCTION
Hardware that limits the opening angle of hinged systems to avoid
collision on nearby fixed objects. Also used as child safety device
TECHNICAL FEATURES
•
Perfect fit at all opening Alumil systems
•
Fits all standard Euro groove and PVC sash groove systems
•
Available for bottom hung, top hung and side hung windows
•
Limiter with adjustable brake for side hung
•
Limiter with open out hold for bottom hung
•
Limiter with open hold and releasable arm
•
Limiters cannot be used to t/t windows
•
95° maximum opening
•
Adjustable opening angle depending on arm placement
MATERIALS
•
Extruded aluminium or stainless steel rods
•
Zamak fixing parts
•
Polyamide sliders / brakes
•
Stainless steel fixings
•
***Materials differ between codes
SURFACE COATING
•
No additional surface coating
CERTIFICATION
•
Alumil 5 Year Guarantee
EX-4167650000 STAY ARM FOR BOTTOM HUNG PVC GROOVE
EX-4211456000 WINDOW ARM LIMITER (HANDLE BLOCK) EURO GROOVE
EX-4731000000 STAY ARM FOR BOTTOM HUNG EURO GROOVE
EX-4731955000 LASER TELESCOPIC 5 POSITION EURO GROOVE STAY ARM TOP HUNG
EX-4741459000 LIMITATION ARMWITH BRAKE FOR SIDE HUNG EURO GROOVE 220mm
EX-4741459800 LIMITATION ARMWITH BRAKE FOR SIDE HUNG EURO GROOVE 480mm
Stay arm for bottom hung
PVC groove
Window arm limiter
(Handle block)
Stay arm for bottom hung
EURO groove
Laser telescopic 5 position
EURO groove stay arm top
hung
Limitation arm with brake for side hung
EURO groove 220mm & 480mm
OPENING LIMITERS
CODES & DESCRIPTIONS
