FUNCTION
Lock for Alumil sliding systems with multiple locking
points and cylinder lock option
TECHNICAL FEATURES
•
Perfect fit for all sliding Alumil systems
•
From 1 to 4 locking points
•
Available version with euro profile cylinder hole
•
Two available gear backsets 7.5 and 15mm
•
Large oval locking points with optional “antilift”
accessory for enhanced security
•
Combi version available with round pins
•
Designed to work with the Alumil 7mm handle
MATERIALS
•
Steel main body and locking points
•
Zamak parts
SURFACE COATING
•
Zamac die-casting components are subjected to
bichromating surface treatment and an additional silver-
colored coating
CERTIFICATION
•
Durability: Grade 5 - 25.000 test cycles [EN 13126-1/19]
•
Corrosion resistance:
- Hardware set: Grade 3 - high - 96h [EN 1670]
- Individual zinc die-cast component with bichromating
treatment: Grade 5 - >1,000h salt-spray test [EN 1670, EN
9227 based on EN 13126-1:2011]
•
Alumil 5 Year Guarantee
EX-4405050901 SLIDING LOCK 1 POINT 120 mm BS7,5
EX-4161000000 SLIDING LOCK 1 POINT COMBI 120 mm BS15
EX-9100001871 SLIDING LOCK 2 POINTS 600 mm BS7,5
EX-4166400600 SLIDING LOCK 2 POINTS COMBI 600 mm BS15
EX-6308310011 SLIDING LOCK 2 POINTS 1000 mm BS7,5
EX-4166401000 SLIDING LOCK 3 POINTS COMBI 1000 mm BS15
EX-4163831800 SLIDING LOCK 3 POINTS 1800 mm BS7,5
EX-4166401600 SLIDING LOCK 4 POINTS COMBI 1600 mm BS15
EX-6309540311 SLIDING LOCK 1 POINT 300 mm BS15
EX-6308800011 SLIDING LOCK STRIKER SILVER STRAIGHT BACK
EX-4404064100 SLIDING LOCK 2 POINTS 600 mm BS15
EX-6304064301 SLIDING LOCK STRIKER SILVER CONE BACK
EX-6309541000 SLIDING LOCK 2 POINTS 1000 mm BS15
EX-6301819601 SLIDING LOCK EXTRA ANTILIFT STRIKER
EX-4404164100 SLIDING LOCK 2 POINTS 1600 mm BS15
EX-4409542600 SLIDING LOCK 4 POINTS 1600 mm BS15
EX-6309540411 SLIDING LOCK 3 POINTS 1800 mm BS15
EX-6301538600 SLIDING LOCK 2 POINTS 1600 mm BS15 WITH CYLINDER HOLE
Striker with antilift
BS 7,5mm
BS 15mm
MULTI POINT LOCK FOR SLIDING SYSTEMS
CODES & DESCRIPTIONS
19
Standard
locking
Combi Version
locking
