FUNCTION
The latch plate is permanently released upon electrical contact.
Locking function is restored upon the door being opened and closed
again. With hold open lever
TECHNICAL FEATURES
•
Fafix adjustable latch (5mm.)
•
Reversible
•
Hold open function
•
On-off function to set the open position time
•
Low core dimension for all use
•
Slide, made a wedge (permanent release), make easy latch bolt
released
•
Power supply unified version alternate current and direct current
•
Long life span 250.000 cycles
•
Input from 0.5 to 0.8 A
•
Power supply 6-12 V AC - DC or 24 V AC - DC
•
For locks 72, 85 and 92mm backset
MATERIALS
•
Zamak
SURFACE COATING
•
No additional surface coating
CERTIFICATION
•
Pressure resistance: Individual test on the latch bolt 350kg
•
Alumil 5 Year Guarantee
EX-4851621900
ADJUSTABLE ELECTRIC LATCH PLATE
ON-OFF and Hold-open function
Fafix - adjustable latch
52.5
45.4
75
28
19.5
9.4
ELECTRIC LATCH PLATE
CODES & DESCRIPTIONS
