FUNCTION
Concealed panic exit device for standard and fire rated
doors with security mortise lock
TECHNICAL FEATURES
•
Reversible for left and right doors
•
For single leaf doors with metal profile
•
Suitable for fire rated doors
•
Can be combined with external handle
•
1 or 3 locking points
•
U-shape or flat forend
•
Backset 35mm
•
Bar, cylinder, strike plate for lock and external
handle are separate codes
MATERIALS
•
Stainless steel U-shape and flat forend
•
Varnished steel and anodized aluminum bars
SURFACE COATING
•
No additional surface treatment
CERTIFICATION
•
CE certified for doors on hinges or pivots with
weight over 200kg, height not higher than 2520mm
and width not greater than 1320mm [EN 1125]
•
Alumil 5 Year Guarantee
EX-4809901000
CONCEALED PANIC BAR MECHANISM BASIC KIT 1 POINT 35MM U-SHAPE
EX-4809911000
CONCEALED PANIC BAR MECHANISM BASIC KIT 1 POINT 35ΜΜ FLAT FRONT
EX-4809913000
CONCEALED PANIC BAR MECHANISM BASIC KIT 3 POINT 35ΜΜ FLAT FRONT
EX-4801921024
BAR 1200mm FOR CONCEALED PANIC BAR MECHANISM GREY RAL 7040
EX-4801921035
BAR 1200mm FOR CONCEALED PANIC BAR MECHANISM RED RAL 3020
EX-4559501000
HANDLE OUTSIDE FOR CONCEALED PANIC BAR MECHANISM BLACK
EX-4809932000
STRIKER 1 POINT FOR CONCEALED PANIC BAR MECHANISM
1 locking point
CODES & DESCRIPTIONS
PANIC BAR MECHANISM CONCEALED
42
3 locking points
