FUNCTION
Mechanism of rotating slats for enhanced shading
TECHNICAL FEATURES
•
Rotation with lever or knob
•
Perfect fit for 25 and 35mm width grooves
•
65mm shutter slat
•
5m long mechanism to be cut at the required length
•
Reducer used for bottom fixed shutter slat
•
Fast and easy installation
•
Robust solution
MATERIALS
•
Extruded aluminium main body
•
Plastic slat fixing points
•
Inox rods
•
Zamak gears
•
Plastic compensators
SURFACE COATING
•
Black anodized main body
CERTIFICATION
•
Certified according to EN 13659 EU
•
ISO 9001:2008
•
Alumil 5 Year Guarantee
EX-4551002503 PAIR OF ADJUSTABLE SLAT MECHANISMS 5m 25mm
EX-4551022503 ROTATING KNOB FOR 25mm
EX-4551012503 ROTATING LEVER FOR 25mm
EX-4551003503 PAIR OF ADJUSTABLE SLAT MECHANISMS 5m 35mm
EX-4551023503 ROTATING KNOB FOR 35mm
EX-4551013503 ROTATING LEVER FOR 35mm
Rotating knob
for 25mm
Rotating knob
for 35mm
Rotating lever
for 25mm
Rotating lever
for 35mm
CODES & DESCRIPTIONS
ADJUSTABLE SLAT MECHANISM FOR SHUTTERS
