FUNCTION
External application panic bar mechanism for
single and double, standard and fire doors
TECHNICAL FEATURES
•
Reversible for left and right doors
•
Modular system for 1, 2 and 3 locking points
•
Second sash locking top and bottom
•
Easy to install after fabrication and installation
of the sash
•
Small sizes for minimal aesthetic impact
•
Second sash locking
•
External handle with lock available
•
Vertical rods with covers
MATERIALS
•
Steel bar
•
Steel rods
•
Zamak levers
•
Steel covers
SURFACE COATING
•
Black powder coating mechanism
•
Silver and red bars
•
Black outside handle
CERTIFICATION
•
CE certified for doors on hinges or pivots with
weight over 200kg, height not higher than 2520mm
and width non greater than 1320mm [EN 1125]
•
Alumil 5 Year Guarantee
EX-4809601000
PANIC BAR MECHANISM BASIC KIT WITH CENTRAL LOCKING POINT BLACK
EX-4809601100
BAR 1200mm FOR PANIC BAR MECHANISM RED
EX-4809601200
BAR 1200mm FOR PANIC BAR MECHANISM SILVER
EX-4809601500
KIT FOR PANIC BAR MECHANISM WITH UPPER AND LOWER LOCKING POINTS BLACK
EX-4809601600
CONNECTION RODS FOR PANIC BAR MECHANISM FOR 2.4m DOOR BLACK
EX-4809601700
OUTSIDE HANDLE WITH CYLINDER FOR PANIC BAR MECHANISM BLACK
71
103
34,2
47
96
400-2000mm
53
CODES & DESCRIPTIONS
PANIC BAR MECHANISM STANDARD
