FUNCTION
Drop down and threshold seals for all Alumil doors. Wind seals
provide sealing from wind, dust and noise
TECHNICAL FEATURES
•
Perfect fit for all Alumil door systems
•
Automatic drop down seals with single (Alu-plus) and double
plungers (Auto-Seal)
•
Graduated scissor mechanism for hinge side drop first ensures
no seal dragging
•
Adjustable drop pressure for perfect insulation
•
Double plunger mechanism removable from hinge side after
installation
•
Double plunger includes closing plug, strikers
•
Double plunger can be cut up to 110mm in length
•
Single plunger can be cut up to 150mm in length
•
Automatic drop down seals will not seal perfectly from water
•
Threshold seals for floor and door
•
Floor threshold seal to be installed with silicone or screws
•
Well installed floor threshold seals from fire, smoke, water, wind
and noise
•
Threshold can be fixed after door installation
•
15mm high threshold complies with EU standards
MATERIALS
•
Extruded aluminium 6060 T6 main body
•
Polyamide PA 20% glass caps
•
Polyamide PA 20% glass actuators
•
Galvanized plunger spring
•
Self extinguishing TP seal for plungers
•
Self extinguishing Silicone seal for threshold
SURFACE COATING
•
Aluminium mill finish for automatic drop down seals
•
Silver anodized aluminium threshold
•
Threshold seal and endcaps in Grey RAL 7035
CERTIFICATION
•
Acoustic sealing certification by IFT Rosenheim for
automatic plungers
•
Durability testing for 200.000 closing cycles
•
Alumil 5 Year Guarantee
EX-4710080000 AUTO-SEAL RUBBER WEATHER BARRIER L:800mm.
EX-7101043000 WATERPROOF THRESHOLD ULISSE LIGHT 430MM
EX-4710090000 AUTO-SEAL RUBBER WEATHER BARRIER L:900mm.
EX-7101073000 WATERPROOF THRESHOLD ULISSE LIGHT 730MM
EX-4710100000 AUTO-SEAL RUBBER WEATHER BARRIER L:1000mm.
EX-7101103000 WATERPROOF THRESHOLD ULISSE LIGHT 1030MM
EX-4710110000 AUTO-SEAL RUBBER WEATHER BARRIER L:1100mm.
EX-7101133000 WATERPROOF THRESHOLD ULISSE LIGHT 1330MM
EX-4716093000 ADJUSTABLE RUBBER WINDBREAK ALU PLUS 930MM
EX-7101163000 WATERPROOF THRESHOLD ULISSE LIGHT 1630MM
EX-4716103000 ADJUSTABLE RUBBER WINDBREAK ALU PLUS 1030MM
EX-7102043000 PENSTOCK BRUSH ULISSE LIGHT 430MM
EX-4716113000 ADJUSTABLE RUBBER WINDBREAK ALU PLUS 1130MM
EX-7102073000 PENSTOCK BRUSH ULISSE LIGHT 730MM
EX-4716200000 ACTUATOR PIVOT FOR WINDBREAK ALU PLUS BLACK
EX-7102103000 PENSTOCK BRUSH ULISSE LIGHT 1030MM
EX-4716300000 DOUBLE PLUNGER KIT FOR WINDBREAK ALU PLUS
EX-7102133000 PENSTOCK BRUSH ULISSE LIGHT 1330MM
EX-4702000002 STOP FOR SHUTTERSWHITE
EX-7102163000 PENSTOCK BRUSH ULISSE LIGHT 1630MM
EX-4702000003 STOP FOR SHUTTERS BLACK
Double / Auto-seal
Single / Alu-plus
Brush
Waterproof
threshold
DOOR WIND SEALS
CODES & DESCRIPTIONS
