FUNCTION
Heavy duty Alumil Supreme Door hinge
TECHNICAL FEATURES
•
Fully independent 3D micro-adjustment (height, side to side
and gasket pressure)
•
Remains aligned even when fully adjusted
•
Easy installation without any inserts in the chambers
•
Same hinge for right and left and inward-outward application
•
Burglar proof pin
•
Self-taping screw or rivet application (both included in the kit)
•
Tested up to 160kg
•
Triple hinge design for enhanced stability
•
Complete fixing set and installation instructions in one package
•
Alumil branded with engraved Alumil logo
MATERIALS
•
Full extruded aluminium main body
•
Stainless steel pin
•
Glass reinforced bushings
•
Full stainless steel fixing screws
•
CNC machined adjustment plate
SURFACE COATING
•
Silver anodized
•
Inox anodized
•
Black anodized
CERTIFICATION
•
160kg tested
•
Alumil 5 Year Guarantee
INT-3607795011
ALUMIL HINGE 3D FOR SD DOORS INOX ANODIZED
INT-3607795033
ALUMIL HINGE 3D FOR SD DOORS SILVER ANODIZED
INT-3607795045
ALUMIL HINGE 3D FOR SD DOORS BLACK ANODIZED
ALUMIL SUPREME DOOR HINGE
CODES & DESCRIPTIONS
