FUNCTION
Standard euro groove hinges for small doors and windows
TECHNICAL FEATURES
•
Perfect fit for all opening Alumil systems
•
Fits all standard 14/18 frame – 15/20 sash groove systems
•
Door height adjustment
•
For up to 70kg with 2 hinges and 80kg for 3 hinges
•
Placement of hinges on top and bottom
•
Third hinge placed below the top hinge
•
Packaged in pairs, not assembled
•
Third screw for extra stability
MATERIALS
•
Full extruded aluminium main body
•
Polyamide bushings
•
Inox screws and fixing plates
•
Galvanized pin
SURFACE COATING
•
White powder coating RAL 9016
•
Black powder coating RAL 9005 mat
•
Mill finish / Special colors upon request
CERTIFICATION
•
Alumil 5 Year Guarantee
EX-3504400202
ALUMINIUM HINGE ALUMIL SCREWS-PLATE INOX WHITE
EX-3504400203
ALUMINIUM HINGE ALUMIL SCREWS-PLATE INOX BLACK
ALUMIL STANDARD EURO GROOVE HINGE
CODES & DESCRIPTIONS
