FUNCTION
Euro groove heavy duty hinges for doors
TECHNICAL FEATURES
•
Perfect fit for all euro groove Alumil doors
•
Fully independent 3D adjustment (up/down, side to side and
gasket pressure)
•
Weight capacity with two hinges:
- 120 kg for residential use
- 110 kg for commercial use
- 100 kg for commercial use combined with a door closer
- 90 kg for commercial use combined with a door closer
and a limitation arm
•
A third top assembled hinge, close to the upper one, increase
weight capacity by 15%. No capacity increase is obtained if the
third hinge is assembled in the middle of the door
MATERIALS
•
Full extruded aluminium main body
•
Polyamide bushings
•
Inox screws and fixing plates
•
Stainless steel pin
SURFACE COATING
•
White powder coated RAL 9016
•
Black powder coated RAL 9005
•
Silver anodization
CERTIFICATION
•
Certified according to EN 1935:2004 + EC1 2007: Grade
13 hinge
•
Durability:
- Grade 7 - Up to 200.000 cycles
- Individual test: Tested up to 5.000.000 cycles - 120kg
•
Sash mass: 120kg
•
Corrosion resistance: Grade 4 - >240hours [EN 1670]
•
Suitable for burglar-proof doors [EN 1627]
•
Alumil 5 Year Guarantee
EX-3500567102
EURO GROOVE HEAVY DUTY HINGE 3D WHITE 120kg
EX-3500567103
EURO GROOVE HEAVY DUTY HINGE 3D BLACK 120kg
EX-3500567109
EURO GROOVE HEAVY DUTY HINGE 3D SILVER 120kg
HEAVY DUTY EURO GROOVE DOOR HINGES
CODES & DESCRIPTIONS
