FUNCTION
External heavy duty hinges for doors
TECHNICAL FEATURES
•
65mm for all inwards and outwards opening doors
•
86 and 91mm hole distance for reversing profiles
•
Fully independent 3D adjustment without raising or removing the door
•
Max certified weight is 180kg for 200.000 cycles
•
Made in Germany
•
Antitheft system for pin removal with integrated screw
•
Versions for thermally broken profiles with screws and for single wall
profiles with fixing plates
•
Hinges with fixing plates and for uneven sash/frame are with
preinstalled spacers
•
Spacers available for hinges with screws in 3 colors
•
Fixing plates with 21mm depth for small chambers
•
Triple version available for weight up to 220kg
•
Drilling jigs available according to the hinge
•
Rust proof continuous bearing ping / no necessity for lubrication
MATERIALS
•
Full extruded aluminium body
•
Stainless steel pin
•
Nylon caps and bushings
•
All metal parts are corrosion resistant
SURFACE COATING
•
White powder coated RAL 9010
•
Black anodized
•
Silver anodized
CERTIFICATION
•
Certified according to EN 1935: Grade 14 hinge
•
Durability: Grade 7 - Up to 200.000 cycles
•
Corrosion resistance: Grade 4 - >240hours [EN 1670]
•
Suitable for fire/smoke retardant doors [EN 1634-1]
•
Suitable for burglar-proof doors [EN 1627]
•
3 star rating by SKG
•
Alumil 5 Year Guarantee
EX-3602190112 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm BLACK ANOD
EX-3602190111 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm SILVER ANOD
EX-3602190102 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WHITE RAL9010
EX-3601590112 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 15mm BLACK ANOD
EX-3601590111 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 15mm SILVER ANOD
EX-3601590102 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 15mm WHITE RAL9010
EX-3600990112 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm BLACK ANOD
EX-3600990111 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm SILVER ANOD
EX-3600990102 DOOR HINGE 65mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm WHITE RAL9010
EX-3602190512 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm BLACK ANOD
EX-3602190511 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm SILVER ANOD
EX-3602190502 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm WHITE RAL9010
EX-3600990512 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm BLACK ANOD
EX-3600990511 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm SILVER ANOD
EX-3600990502 DOOR HINGE 91,5mm DOUBLE WITH PLATE 21mm WITH ADDITION 9mm WHITE RAL9010
EX-3605890112 DOUBLE DOOR HINGE 65mm WITH SCREW 58mm BLACK ANOD
EX-3605890111 DOUBLE DOOR HINGE 65mm WITH SCREW 58mm SILVER ANOD
EX-3605890102 DOUBLE DOOR HINGE 65mm WITH SCREW 58mm WHITE RAL9010
EX-3605891112 DOUBLE DOOR HINGE 86mm WITH SCREW 58mm BLACK ANOD
EX-3605891111 DOUBLE DOOR HINGE 86mm WITH SCREW 58mm SILVER ANOD
EX-3605891102 DOUBLE DOOR HINGE 86mm WITH SCREW 58mm WHITE RAL9010
EX-3605895112 TRIPLE DOOR HINGE 65mm WITH SCREW 58mm BLACK ANOD
EX-3605895111 TRIPLE DOOR HINGE 65mm WITH SCREW 58mm SILVER ANOD
EX-3605895102 TRIPLE DOOR HINGE 65mm WITH SCREW 58mm WHITE RAL9010
EX-3609591200 DRILL JIG - DOUBLE HINGE WITH PLATE 65mm WITH ADDITION 15mm
EX-3600910100 DRILL JIG - DOUBLE HINGE WITH PLATE 65mm WITH ADDITION 9mm
EX-3600010500 DRILL JIG - DOUBLE HINGE WITH PLATE 91,5mm
EX-3600910500 DRILL JIG - DOUBLE HINGE WITH PLATE 91,5mm WITH ADDITION 9mm
EX-3609565200 DRILL JIG - DOUBLE HINGE WITH SCREW / PLATE 65mm FOR FLAT PROFILES
EX-3608865200 DRILL JIG - DOUBLE HINGE WITH SCREW 65mm WITH ADDITION 15mm
EX-3601610100 DRILL JIG - DOUBLE HINGE WITH SCREW 65mm WITH ADDITION 7,5mm
EX-3600011100 DRILL JIG - DOUBLE HINGE WITH SCREW 86mm FOR FLAT PROFILES
EX-3601611100 DRILL JIG - DOUBLE HINGE WITH SCREW 86mm WITH ADDITION 7,5mm
